Technical Features:
· Imported Germany second generation balance arm hanging system (optional).
· With Standard surgical light rotating axis system (Patent).
· With Standard butterfly spring braking system, preventing drifting (Patent).
· With standard surgical light focusing (Patent).
· Imported electric commutator system from Germany: LED bulb imported from Germany.
· High grade power system from Taiwan.
· ABS operate handle in the lamp rim.
· Reflector with big headlight cup, 3w high power LED bulb.
Technical Parameters：
| MODEL |
BT-LED720 |
BT-LED520 |
| Maximum Light Output Measured in 1m(lux),Ec |
160,000 |
130,000 |
| Color Temperature (Kelvin) |
4,300 |
4,300 |
| Adjustable Color Temperature (Kelvin) (Optional function) |
3600-5600 |
3600-5600 |
| Color Rendering Index (CRI) |
96 |
96 |
| Red Color Index (R9) |
96 |
96 |
| Electronic ray intensity control |
standard |
standard |
| Dimming range |
10—100% |
10—100% |
| Temp rise(Surgeon head)(℃) |
0.5 |
0.5 |
| Temp rise(surgical field)(℃) |
2 |
2 |
| Effective Focusing Depth(cm) |
60-150 |
60-150 |
| Total Irradiance Ee (W/m2) |
530 |
530 |
| Radiant Power/ Intensity Ee/ Ec (mW/m2lux) |
3.3 |
3.3 |
| Lighting Spot Size (mm) |
100-260 |
100-260 |
| Bulb Type |
LED |
LED |
| Average Bulb Life (hours) |
60,000 |
60,000 |
| Bulb Quantity |
48LEDS(main bulb) +96LEDS(auxiliary bulb) |
24LEDS(main bulb)+48 LEDS(auxiliary bulb) |
| Depth of Illumination L1+L2 (cm) |
≥130 |
≥130 |
| Power Consumption of the Light head (W) |
70 |
50 |
| Height adjustment(cm) |
118 |
118 |
| Power Input |
100-240VAC, 50/60Hz |
100-240VAC, 50/60Hz |
